Config

You have hardware with Meshcore ready? Let's get you set up on the EU/UK (Narrow) preset and add all the relevant channels.

This sets your device to the EU/UK (Narrow) Meshcore preset and default scope to de-bebb (Berlin/Brandenburg).

Frequency869.618 MHz

Bandwidth62.5 kHz

Spreading factorSF 8

Coding rate4/8

TX power22 dBm (default)

Scopede-bebb

This adds the DWebCamp hashtag channels to your device.

Channel	Scope	Description
#dwebcamp	`de-bebb`	DWebCamp main public channel
#schedule	`de-bebb`	schedule for the DWebCamp stages
#workshop	`de-bebb`	for the RF Mesh → Workshop
#bot	`de-bebb`	an ask-me-anything bot answering your questions
#berlinmesh	`de-bebb`	the Berlin local Chaos Mesh community and meetup
#berlinbrandenburg	`de-bebb`	the Berlin/Brandenburg regional channel

USB companion nodes only, in a Chromium browser over HTTPS. On a phone or over Bluetooth, use the MeshCore app.

Apps

iOS - MeshCore on the App Store ↗
Android - MeshCore on Google Play ↗
Linux / macOS - MeshCLI (meshcore-cli) ↗, installed with pipx install meshcore-cli

Meshtastic

Region EU_868 · Preset MediumFast

Scan with the Meshtastic app to load the DWeb Camp preset + channels, or open the import link ↗.

Full config: Codeberg: meshtastic/berlin.yml ↗

Reticulum

[[RNode Reticulum Berlin]]
  type = RNodeInterface
  enabled = yes
  frequency = 869475000
  bandwidth = 125000
  spreadingfactor = 7
  codingrate = 5
  txpower = 22

More info: Berlin Chaos Mesh: Reticulum Berlin 869.475 MHz / 125 kHz / SF 7 / CR 5 ↗
